80W 100W 150W 180wlaser Tube Laser Engraving Machine

80W 100W 150W 180wlaser Tube Laser Engraving Machine
Price: US $ 6000-8000/Set
Trade Terms: FOB,CIF
Min Order: 1/Set
Pay Type: L/C,T/T,Western Union
80W 100W 150W 180W Laser Tube Laser Engraving Machine
1. Machine features:
1) Continuous & rapid curve cutting function; Selecting shortest path function.
2) Adopts the new high-efficiency laser tube, the laser beam is more stable than the traditional type, and the life time of the laser tube can be over 10000 hours.
3) The mechanical structure is strong and stable, making the machine to run at high precision.
4) The electrical ability is stable, the engraving speed is high, and the precision is high.
5) Advanced DSP control system, professional motion control chip, consecutive high speed curve cutting and the shortest path selection function improve the working efficiency a lot.
6) LaserCut software compatibility with AutoCAD/Coredraw/Cam/Photoshop/Taijima designing program, output designs directly.
7) USB Interface, with mass storage device; Improve working-speed & working efficiency.
8) Taiwan HIWIN linear guide rail.


2. Applicable industry:
Label processing, Embroidery, advertising, decoration, arts and crafts, electronics, electric appliances, mould industry, packing industry, etc.


3. Applicable Materials:
Acrylic, wood planks, label, fabric, paper ware, bamboo ware, double color board, paper, leather, shell, coconut shell, ox horn, resin animal grease, ABS board, lamp shade, embroidery, leather, synthetic leather, artificial leather, glass, marble, crystal, etc.




Laser Engraving machine with Double-Head, Laser Cutting Engraving machine, Laser Engraving & Cutting machine, Laser Engraver, Laser Cutter, Laser Cutting machine.

4. Technical parameters:
ModelTZJD-1610D
Working  area1600mm*1000mm
Laser  power60w/80w/100w/130w/150w*2
Laser  typeCO2  Sealed  laser  tube  ,   10.6μ m,   water-cooled
Cooling  typeWater-cooling/Water  chiller
Engraving  speed0-60000mm/min
Cutting  speed0-50000mm/min
Total  power2KW/H
Drive  motorsStepper/Servo(option)
Laser  output  control0-100%  set  by  software
Min.   engraving  sizeChinese:   2.0mm*2.0mm,       English  letter:     1.0mm*1.0mm
Highest  scanning  precision4000DPI
Locating  accuracy≤ +0.01mm
Controlling  softwareDSP  control  system
Operating  softwareLaserCut
Graphic  format  supportedDST  PLT  BMP  DXF  DWG  AI  LAS, etc
Compatible  softwareCORELDRAW, PHOTOSHOP,   AUTOCAD, TAJIMA, etc.
Color  separationYes
Drive  systemHigh-precision  3-phase  stepper  motor
Auxiliary  equipmentsExhaust  fan  and  air  exhaust  pipe,   red-dot  position  system,   focus  lens  &   reflection  mirrors,   auto-focus  device,   up  &   down  device.
Power  supplyAc110v/AC220V± 10%,   50HZ/60HZ
Working  environmentTemperature: 0-45,   Humidity  5-95%(No  condensate  water)
Packing  size1.93m*1.54m*1.35m
Net  weight450KG
Machine  availablerotary  device,   honeycomb  worktable,   etc.

5. Packages: Solid seaworthy wood box package with steel belt.

6. Guarantee and After-sales service:
1)  The quality warranty period is 24 months which counted from the day that the shipping commodity arrived at the port of destination, excluding the physical damage, We will provide you with the fittings for free during the guarantee period. But please kindly note that all users are kindly required to return us the damaged fittings by courier with your charge before we send back the alternative fitting parts. After warranty period, the fittings which you need repaired or changed should be in charge by you, and it will be reasonable charged.
2)  Since it is difficult for our engineer to maintain the machine by face to face, we will create a plenty of online-supports. That is to say, we will give you technical supports by email, MSN/Skype, camera, video, telephone and fax when user meets some problems on installing, operating, adjusting, maintaining, and so on.
3) When you meet some problems with installing, using or adjusting, but our online-support can not solve it, we can offer Door to Door service. If you need our engineer(s) to assemble or maintain or adjust the machine in your area, you would like to be required to assist us to go through the visa formality, traveling expenses prepaid and accommodation arrangement during the business trip and the service period before they dispatched. And please kindly arrange the translating person for the service engineer during their service period. Otherwise, you also can arrange your engineer to come to visit our factory to get a long-term free technical training.

7. Traning to use:
1)  We will supply you with the operation and installation manual in English version together with the machine, including introduction for the composing of equipment, working principle, common knowledge of computer, controlling principle of electronic devices, daily maintenance measures. Personal demonstration will be supplied for equipment installing, adjusting, operating, programming of computer and common malfunction eliminating measures, etc.
2)  We will supply you with brochures for simple trouble shootings of the machine which can help you deal with the common problems happened unexpectedly. Meanwhile, one set of "Instruction Book", "Operation Manual" and "Training Video Disk" for machine / software will be also sent to you together with the machine that could be easily understood and kindly handled by you and your customer.

8. Company information:
Tengzhou Jianda CNC Machine Co., Ltd specialized in woodworking machine,advertising machine, marble/stone engraving machine, laser engraving cutting machinemetal mould machine, double heads engraving machine,cylinder engraving machine, etc. The company was one of companies that can research & develop the advanced CNC Machines, which have laid the foundation in the domestic market. our machines have already exported to USA, Canada, England, Australia, Russia, India and so on.

9. FAQ:
1) How long is the delivery time?
For standard machines, it would be 5-8 days; For non-standard machines and customized machines according to client s specific requirements, it would be 8 to 15 days.

2) How about the payment terms?
T/T, West Union, L/C

3) Do You Arrange Shipment For The Machines?
Yes, dear esteemed customers, for FOB or CIF price, we will arrange shipment for you. For EXW price, clients need to arrange shipment by themselves or their agents.

4) If some problems happened to this machine during warranty period, what should I do?
We will supply free parts in machine warranty period if machine have some problem. While we also supply free after-service forever, so any doubts, just let us know, we will give you solutions in 24 hours.

5) What is the MOQ?
MOQ for our products is 1 set machine, we could send it to your country port if you tell detail information about your country port.

10. Contact information:
Mobile: +86-18615627569

11. Machine accessories:
 Machine ModelTZJD-1610D
NumberName Quantitythe area of placement
1air pump1the inside of mainframe-box
2water pump1the inside of mainframe-box,for low power laser tube
industrial chiller/the inside of mainframe-box,for high power laser tube
3wind pipe1the inside of mainframe-box
4control line1the inside of mainframe-box
5specification1CD in the pocket
6software1
7Controller Card1the inside of file pocket
8softdog1the inside of file pocket
9toolbox1the inside of mainframe-box
10power wire1the inside of toolbox
11cotton stick1the inside of toolbox
12focaling stick1the inside of toolbox
13lozengel allen  wrench 1the inside of toolbox
14spanner to load and unload lens1the inside of toolbox
15nut of loading card/the inside of toolbox
16fixed binding wire  the inside of toolbox
optional accessorieslimit switch the inside of toolbox
opto-electrical switch the inside of toolbox
nut the inside of toolbox
blank panel the inside of toolbox
rotary device the inside of mainframe-box
lens the inside of toolbox
rotary device the inside of mainframe-box
Prod Model: TZJD-1610D
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Engraving Machine Type: Laser Engraving Cuttingmachine
Laser Head: Total Two
Laser Tube: 60W 80W 100W 130W 150W 180W
Drive Motor: AC Stepper/Servo Drive
Certifications: SGS, Ce, ISO 9001, FDA, BV
Guide Rails: Imported Hiwin Square Guide Rail
Control System: Ruida, Leetro
Current Voltage: AC Single-Phase 220V/50Hz
Interface: USB
Working Table: Knifebar and Honeycomb
