Features:
* Wired system and BUS system compatible, holographic spot real-time report.
* Unique DSP chip, patented multi-dimensional mistake-corrective code, true detection alarm technology.
* Adopts offset parabola highly accurate optical focusing mirror.
* Two groups of individual fine tuner, built-in optical collimating mirror.
* nique displacing receiving, transmitting parts with big power, power surplus rate reaches 90%.
* Full function checking, self-adaption in environment and trouble locking.
* Patented balanced checking, unique digital filtering,
* Adopts solid relay with long usage, non-contact, low voltage and little power consumption.
* 50, 100, 150, 200, 250 meters for option
Parameter:
| Model | SFB-50 | SFB-100 | SFB-150 | SFB-200 | SFB-250 |
| Distance(outdoor) | 50m | 100m | 150m | 200m | 250m |
| Operation current | 60mA | 65mA | 65mA | 65mA | 70mA |
| Operation voltage | DC 9-24V AC 11-18V |
| Lens | Nonspherical crystal lens |
| Response time | 50-700ms |
| Alarm output time | 2S |
| Alarm output contact | NC&NO contact rating AV/DC 30V/0.5A |
| Tamper Output | NC contact rating AV/DC 24V/0.5mA |
| Beams adjustment | V: 20°(±10°) H: 180°(±90°) |
| Operation temperature | -25ºC~60ºC 5%---95% |
With over 8 years experiences in electronics business, Sunlit Technology (H. K) Ltd. has developed itself as one of the very professional providers of electronics such as intrusion alarm including motion detector, outdoor PIR detector, infrared beams detectors, photoelectric sensors, alarm control panel, glass break detector, smoke detector, gas leakage detector, power supply such as batteries, inverters, CCTV systems such as gun cameras, integrared infrared cameras, dome cameras, IP cameras, DVR, etc with a comprehensive range of hi-tech products to meet the needs of today highly developing markets under the hard work of its 220 employees.
Sunlit-tech has been devoting its entire efforts to the R&D manufacturing and marketing in electronics continually. Its factory is equipped with advanced equipments like SMT machines, plastic jointing machine, soldering machine, testing devices etc. Most of Sunlit products have got CE approvals and some of them are with UL certificates.
Aiming at Sincere cooperation & mutual benefits, Sunlit has obtained good reputation around the world especially in America, Europe, South Africa, Middle East and Asia with its wide products range, very stabl quality and hot competitive price and after-sale service!
OEM/ODM requests will also be well performed due to our successful 2 years OEM experiences. Sunlit is sure to make you and your company feeling successful like in the sunshine!
