| Price: | US $ 12-30/Piece |
|---|---|
| Min Order: | 100/Piece |
| Pay Type: | T/T,Western Union,Paypal |
| Prod Model: | TFT1781A |
|---|---|
| LCD Type: | TFT |
| Viewing Direction: | 12 O'clock |
| Operating Temperature: | -20~+70 |
| Active Area(W×h): | 222.27X125.28 mm |
| Controller: | Hx8282A14+Hx8696 |
| Backlight: | 3X13-LEDs (White) |
| Interface: | Lvds |
| Screen Size: | ≤17" |
| Application: | Outdoor |
| Aspect Ratio: | 16:9 |
| Feature: | Touch Display |
| Type: | TFT |
| Widescreen: | Widescreen |
| Response Time: | 6ms |
| 3D: | Not 3D |
| Interface Type: | Lvds |
| Optimum Resolution: | 1024X600 |
| LCD Type | TFT IPS |
| Display color | 16.7M |
| Viewing Direction | Free view |
| Operating temperature | -20~+70 ºC |
| Storage temperature | -30~+80 ºC |
| Module size | Refer to outline drawing |
| Active Area(W×H) | 216.96x135.6 mm |
| Number of Dots | 1280x800 dots |
| Controller | -- |
| Power Supply Voltage | 2.5 V |
| Outline Dimensions | Refer to outline Drawing |
| Backlight | 3x10-LEDs (white) pcs |
| Weight | --g |
| Interface | LVDS |
| Q1:Are you a factory or trading company? | A1: We are manufacturer. Please refer to our company show |
| Q2:Where is your factory located?How can I visit there? | A2:Our factory is located in Hunan,China.Welcome to visit our factory. We could pick you up in Changsha Huanghua Airport, or High-speed train Zhuzhou Xi station. |
| Q3:How can I get some samples? | A3:We don't provide free one, but we will minus the extra price when you reorder with the suitable quantity. And you will win the 1-3% discount. |
| Q4:How does your factory do regarding quality control? | A4:Quality is the priority. Our factory has gained ISO9001 RoHS SGS certification. |
| Cooperate Supplier | Tianma, Innolux, Sumsung, LG, Varitronix, CPT, BOE,HSD,Chi mei |
| Company development plan | Our company prepared attend electronics show in Korea,2017 |
| Packaging & Delivery | Packaging Details: in an anti-statics bag packed in carton or according to the customer's requirement Delivery Detail: 5-7 days for sample and 25-30 days for mass production |
| 1. Chracter lcd (8x1, 8x2, 16x1, 16x2, 16x4, 20x2, 20x4 , etc.) |
| 2. Graphic lcd (122x32, 128x64, 192x64, 240x128, 320x240 , etc.) |
| 3.TFT LCD (1.44", 1.77", 2", 2.2",2.4", 2.8", 3",3.2", 3.5", 4.3", 5", 5.5", 5.7", 6.2", 7", 8", 9", 9.7".10.1", 10.2", 10.4",17" , etc. |
| 4. TN/STN/HTN/VA segment custom lcd,LED backlight panel |
| All kinds of LCD Module can customize according to customer`s requirement. |
