60W 80W 100W Multi Functional Rhino Laser Engraving Machine R-9060

Name: 60W 80W 100W Multi Functional Rhino Laser Engraving Machine R-9060
Brand: china-crystals.com
SKU: 705467392
Availability: InStock
Rating: 4.9 (84 reviews)

Price:	US $ 3000-5000/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Product Specifications

Prod Model:	R-9060
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Engraving Speed:	0-64000mm/Min
Laser Output:	1-100%Software Setting
Laser Type:	CO2 Sealed Laser Tube
Resetting Positioning Accuracy:	≤±0.01mm
Laser Tube Powe:	60W 80W 100W 120W 130W 150W 260W
Cutting Speed:	0-36000mm/Min
Cooling Mode:	Circulating-Water-Cooling
Focus Len:	Imported Lens From USA
Graphic Format Supported:	Ai, Plt, Dxf, BMP, Dst, Dwg
Control Systerm:	DSP Control

Product Description

60w 80w 100w multi functional rhino Laser engraving Machine R-9060

Standard Configuration:

(01) User manual of machine(English version)

(02) User manual of software(English)

(03) USB cable (04) Communication cable

(05) Air exhaust fan (06) Air pump

(07) 3 reflecting mirrors (has been installed in the machine)

(08) One focus lens(has been installed in the machine )

(09) One laser tube(has been installed in the machine)

(10) Water chiller

Information:

This laser machine adops DSP & laser power source with self owned property right as well as integrated frame-structure ensure the working stability and reliability, the latest software can support Auto CAD, CorelDRAW,CAM, and other graphical software, and it can to directly output pictures. The USB data interface support heat play & plug, quick data transiting without taking up computer resource. LCD display is easy for user to operate.

Applicable industry:

Advertisement signs and marks making, handicraft industry, crystal accessories, paper cutting, wood and bamboo industry, printing industry, clothing and leather industry, garment industry, decorative industry, photo frame making and so on.

Applicable materials:

Double color plate,organic glass, glass, acrylic, wood, paper, leather, cloth, rubber, marble, granite, ceramic tile, shell and other non-metal materials.

Fetures:

1.Iron cast wholly frame, floor-type linear guide transmission.

2.High power water cooling brushless motor, more forceful cutting capability, wear well.

3.High speed driver and stepper motor could enhance the machine easy maintenance.

4.Well designed dust and water proof device ensure the machine easy maintenance.

5.Advanced in CNC industry ,break-point memory pointes for 10 pcs, reducing material waster.

6.Self-researched high-efficiency laser power supply

7.High compatibility, applicable for CNC software:type3,Artcam,Castmate,Pore,Weitai,variable CAD/CAM etc. It is easily to process relief sculpture, shadow carving, three dimension characters in fancy style etc.

8.High intention, high precision mechanic structure design, the data control is stable.

Technical parameters:

Notes: The working area and laser power can produce according customers requirments.

Model	R-6090	R-1290	R-1410	R-1610	R-1320	R-1325	R-1630
Engraving Area (mm)W*L	900*600	1200*900	1400*1000	1600*1000	1300*2000	1300*2500	1600*3000
Laser tube power	60W 80W 100W 120W 130W 150W
Laser Type	CO2 sealed laser tube
Engraving Speed	0-64000mm/min
Cutting Speed	0-36000mm/min
Resetting positioning accuracy	≤±0.01mm
Laser Output	1-100%software setting
Cooling mode	Circulating-water-cooling and protection system
Machine control and drive	Speedy DSP controlling, stepper motor
Cutting Platform	knife-strip platform
Min. shaping character	Character2.0mm×2.0mm,English1.0mm×1.0mm
Power Supply	AC220V 50HZ
Operating system	DSP off-line control system
Dictate format	.plt,.dst,.dxf,.bmp,.dwg,.al,*las etc.
Operating Temperature	5°C-40°C
Operating Humidity	5-95%(Free of Condensed Water)
Compatible Software	CorelDraw ,AutoCAD transmit directly
Optional Spare Parts	Rotary system, Industrial Chiller, Infrared Locating System, Laser Tube, Up-down clump
Recommended Spare Parts	Laser Tube
Quotation	FOB QINGDAO CHINA
PS: if you have any requirements about our machine , please feel free to contact with me !

Machine cutting and engraving samples:

FAQ

1.What's the guarantee, in case the machine breaks down?

The machine has one year s guarantee. If it breaks down, generally speaking, our technician will figure out what the problem may be, according to clients feedback. Parts except for consumable parts will be replaced for free if the problems are caused by quality fault.

2.How about the documents after shipment?

After shipment, we ll send all original documents to you by DHL, including Packing List, Commercial Invoice, B/L, and other certificates as required by clients.

3.How long is the delivery time?

For standard machines, it would be 7-10 days; For non-standard machines and customized machines according to client s specific requirements, it would be 15 to 30 days.

4.How's the payment?

Telegraphic Transfer(T/T),L/C or according to your requirement

5.Do You Arrange Shipment For The Machines?

Yes, dear esteemed customers, for FOB or CIF price, we will arrange shipment for you. For EXW price, clients need to arrange shipment by themselves or their agents.

6.How is the packing?

The mini laser engraving machine for glass should be use Water-proof plastic film package with foam protection in each corner
Solid Seaworthy Wood Box Package with Steel Belt
Save space as much as possible for container loading

For more informations ,please feel free to contact me!
