| Price: | US $ 9500/Set |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Set |
| Pay Type: | L/C,T/T,Paypal,Western Union |
Features:
1.Use the advanced diode side-pumped laser technology, with high optical conversion efficiency and stable performance.
2.Fast speed & no touch processing, the heat exchange is little, the material is not easy to distort.
3.With preciser beam mode than YAG lamp-pump laser machine, the high precision is what the YAG Lamp-pump laser machine can not reach.
4.No need to change the consumables (such as laser lamp), free of maintenance,very low operation cost.
5.All the core optical components used such as laser diode, Q-switch crystal,are famous brands with top quality, therefore the whole machine is with very stable performance and long life time.
The fiber laser machine can marking metal(including the rare metals)such as steel,titanium,copper etc,and some of nonmetal such as nylon,light button,ABS,PVC,PES.
The filed with the higher requirement for depth and smoothness such as clock industry,mould industry,bitmap marking and so on.The other field such as electronic component,electrical products.IT industry.auto-parts,metal tools,accurate instruments,present and adornment,medical instruments,high or low voltage electric equipment,etc.
Technical parameters:
1. Laser output power | 75W |
2. Laser wavelength | 1064nm |
3. Standard marking scope | 110 mm*110mm |
4. Selective Marking scope | 70mm*70mm/150 mm*150mm |
5. Beam quality | M2 <3 |
6. Marking depth | 0.01~0.2mm |
7. Marking speed | 7000mm/s |
8.Repeated accuracy | ±0.01mm |
9.Minimum character | 0.1mm |
10.Minimum line width | 0.015mm |
11.Electric power requirement | 380V/50-60Hz220V/50-60Hz |
12.Machine power | 3.5KW |
13. Dimensions :(L*W*H) |
|
Mainframe : | 240mm*1280mm*1200mm |
Control Cabinet : | 590mm*560mm*800mm |
Water Cooling Machine: | 540mm*700mm*900mm |
Samples:
Packaging:
| Prod Model: | DW-75D |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Drive Type: | Stepper Drive |
| Certification: | CE, FDA |
| Laser Type: | Diode |
| Control: | Automatic |
| Current: | AC |
| Condition: | New |
| Engraving Machine Type: | Diode Laser Marking Machine |
| Usage: | Metal and Nonmetal Materials |
| Power: | 75W |
