Product Description
Thickness
3-19mm
Size avaliable
Largest 4200X2440mm
Smallest 250X150mm
Color avaliable
Clear, dark/lake/ocean blue,dark/f/h green,bronze,grey, etc.
Glass types avaliable
Float glass, on-line low-e glass, off-line low-e glass,sunny control glass, acid atteched glass,etc.
Processing Technology Before Tempering
1.Edge processing method: polished edges, beveled edges, chamfered edges or grinding edges
2.Drilling holes
3.Cut out
Product Attributes
1.Safety performance: tempered glass will appear hurtless obtuse angles when breakage.
2. Strength performance: Four times more than ordinary glass.
3. Heat stability performance: Three times more than ordinary glass, could bear the temperature change about 200°C.
4. Tempered glass has a very good performance of anti-curve, anti-impact intensity.
What thickness of glass do i need for my project?
1 Oftentimes 5mm gets passed over for 6mm (1/4") glass. It is only a little more expensive but has enough strength to be used for almost anything from table tops and shelves to glass partitions and railings. Because it's very common it comes in bronze, blue, grey and clear.
2 12mm (1/2") can also be used on the frameless shower doors although it is not as common. 12mm is often seen in frameless railing glass, table tops or raised bar tops.
The thicker you go with glass the darker green the edge of it becomes. If you aren't a fan of the green edge there is a new kind of glass called Starfire. Starfire is made with a low-iron low-lead formula which gives it a crystal clear quality. Your edge is clear with a slight aqua tint to it. It is stunning for table tops, shelves or desk tops.
There are different types of glass if you need added strength or safety. Tempering glass multiplies its strength five times over. A common misperception about tempered glass is that it is unbreakable. Despite its increase in strength on the surface of the glass it, ironically, is more fragile than regular glass on the edges. If you hit regular glass hard enough on its edge you may chip it. Do this to tempered glass however and the whole thing would break into little cubes.
HOT-SALE PROUCTS
| Glass Type | Tempered glass / Toughened glass |
| Color | Clear / Ultra-clear / Green / Grey / Bronze / Blue etc. |
| Maximum Size | 2440*6500mm |
| Minimum Size | 200*300mm |
|
| Thickness | Tempered:4-19mm half tempered :4-12mm |
| Glass Type | Insulated glass |
| Maximum Size | 2500*5000mm |
| Minimum Size | 200*300mm |
| Thickness | 3-19mm |
| Spacer Thickness | 6mm, 9mm, 12mm, 15mm, 16mm, 20mm |
| Regular Size | 5+9A+5 5+9A+5 low-e 5+9A+5 coated
5+12A+5 5+12A+5 low-e 5+12A+5 coated
5+16A+5 5+16A+5 low-e 5+16A+5 coated
5+20A+5 5+20A+5 low-e 5+20A+5 coated
5+24A+5 5+24A+5 low-e 5+24A+5 coated
6+12A+6 6+16A+6 low-e 6+12A+6 coated
6+24A+6 6+24A+6 low-e 6+24A+6 coated
5+12A+5+12A+5 5+12A+5+12A+5 low-e |
| Glass Type | Laminated glass |
| Maximum Size | 2500*7800mm |
| Thickness | 3-19mm |
| Total Thickness | 6.38-80mm |
| PVB | 0.38-2.28mm (0.38mm, 0.76mm, 1.14mm, 1.52mm ) |
| | Arch height< 50mm for curved laminated glass |
| Regular Size | 5+0.38pvb+5 tempered or not 5+0.76pvb+5
6+0.38pvb+6 tempered or not 6+0.76pvb+6
6+1.14pvb+6 tempered or not 8+0.76pvb+8
5+9A+5+9A+5 5+9A+5+9A+5 low-e
5+12A+5+12A+5 5+12A+5+12A+5 low-e
5+0.76pvb+5+9A+5 5+0.76pvb+5+9A+5 low-e
5+0.76pvb+5+12A+5 5+0.76pvb+5+12A+5 low-e
5+1.14pvb+5+9A+5 5+1.14pvb+5+9A+5 low-e
4+9A+4+9A+4 |
| Glass Type | Low-E glass |
| Low-E Types | On line Low-E Glass
Off line Low-E Glass
Double Silver Low-E Glass
Curved Tempered Low-E Glass |
| Maximum Size | 2440*3660mm |
| Minimum Size | 300*700mm |
| Thickness | 3-19mm |
| Popular Size | 2134*3050mm 2440*3050mm 2134*3300mm 2440*3300mm 2134*3660mm 2440*3660mm |
| Glass Type | Online reflective coated glass |
| Color | Silvery grey, grey, blue grey, blue, lake blue, grayish green, |
| Green, bluish green, golden, tawny, champagne, etc. |
| Maximum Size | 2440*7200mm |
| Minimum Size | 350*600mm |
| Thickness | 3, 4, 5, 6, 8, 10, 12, 15mm |
| Packing | Safe Plywood cases and interlayer paper between glass |
| Lead Time | On time delivery |
| Whether u request one container or a bulk shipment,we also attaches great importance to the details in every order,do a good job in each shipment. |
Our company established since 2003. We earn a good branding in China and start exporting to many countries after 2005. Our leading products included tempered glasses, laminated glasses and low-e glasses. We have more than 13 year of exporting experience. We concentrate in details of our products. You should give us a chance to serve you, then you will understand why our client will work with us for many years and do not leave us.
FAQ
Q:What kinds of glass can you provide?
A:laminated glass,tempered glass,insulating glass and low-e glass etc.
Q: What is your minimum order quantity?
A:Our MOQ is one 20 feet container (20-27Tons).We can also do LCL orders.
Q: How can I get samples to check your qulity?
A:We offer samples for free. ALL YOU HAVE TO DO IS ASK!
Q:Can you do OEM Orders?
A:Yes,we hire technicians to design your products as per your specific needs.
Q:What is your trade Term?
A:FOB,CFR,CIF,EXW.
Q:What is your payment term?
A:T/T,L/C, Credit 30-90days.
Q:What is your delivery time?
A:15-30 days,depend on the order quantity.
Founded in 2003, Shandong Jingcheng Glass Technology Co., Ltd. is located in Linqu Economic Development Zone, which has specialized in building glass for more than 10 years.
Leading products: F green/dark float glass, color reflective glass, tempered glass, laminated glass, insulating glass, Low-e glass, bullet glass, fire proof glass, ect.
Our products are manufactured on 2 laminated glass producing lines, 2 insulated hollow glass producing lines, 2 tempered glass producing lines, 2 sets of cutting machines imported from Italy, 2 sets of four grinding edge machines, 2 sets of drilling machines ect.
Experienced more than 10 years of development and sharpening, Jingcheng glass not only creates the brand, but casts its high quality and continual innovation in China since its establishment, now we had opened the international market of building glass industry, do more export to India, Sri Lanka, Costa Rica, Vietnam ect.
Whether u request one container or a bulk shipment, we also attaches great importance to the details in every order, do a good job in each shipment.
Welcome to Jingcheng, we assure u best service.
