Specifications
Automatic PET Bottle Self-Adhesive Labeling Machine
Bottle Material:PET, glass, metal
Speed:12000bph
Automatic PET Bottle Self-Adhesive Labeling Machine
Bottle Material:PET, glass, metal
Speed:12000bph
bottle height:less than 400mm
General description
Rotary self-adhesive labeler is a new machine developed independently for applying self-adhesive and crystal label for brewage, fruit juice beverage, cosmetics and edible oil. With the most up-to-date system of controlling and transporting, the labeler is very accurate and reliable to apply label on containers. Adopting modular design concept, we can design quickly to meet customers 'individual needs. Self-adhesive station is independent modularization that has possibility of combined labeling for cold glue and self-adhesive at the same labeler.
Main features
l Accurately apply label at different speed.
l If changing label shape, need to alter program without exchanging any parts on station.
l Low label consumption (reach international advance standard).
l Transport label driven by servo motor keep applying label accurately.
l Automatic control program make operation easily.
l Label of Releasing and returning is driven independently so as to guarantee servo motor running smoothly.
l Concentration lubrication system.
l Easy and simple to handle and maintain.
Technical parameters
| production speed | 12000BPH |
| Label position | Front, back and neck |
| Bottle holding heads | 15 |
| Label station | 3 |
| labeling accuracy | ±1mm |
| label maximum diameter | 400mm |
| label maximum width | 220mm |
| label minimum width | 15mm |
| bottle size | Thickness≤88mm, height≤400mm |
| label roll inner diameter | φ76mm |
| outline size | 3048X1760X1650 (mm) |
| power | AC380V, 50Hz , 5000W |
Main composition
l Servo Motor For Applying Label: LENZE.
l Servo Motor for Releasing Label: PANASONIC.
l Main Motor: SEW motor including gearbox.
l Motor for Conveyor Belt: SEW motor including gearbox
l Pneumatic Element: SMC. AIRTAC.
l Frequency Converter: DANFOSS.
l PLC Control: SIEMENS.
l Control Elements: P+F. SCHNEIDER. LEUZE.
l Touch Screen: SIEMENS.
