Clear Epoxy Resin Glue for Hairpin (305AB)
Price: |
US $ 8.00-10kg |
Trade Terms: |
FOB,CFR,CIF |
Min Order: |
15kg |
Pay Type: |
L/C,T/T,D/P,Western Union |
Product Specifications
Prod Model: |
305AB |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Shelf Life: |
Six Months |
The Mixing Ratio: |
2:1 |
Classification: |
Room Curing |
Composition: |
Organic Material |
Main Agent Composition: |
Thermosetting Resin |
Promoter Composition: |
Curing Agent |
Application: |
Jewelry, Ornaments |
Color: |
Clear |
Characteristic: |
Waterproof |
Morphology: |
Liquid |
Bonding Function: |
Decoration;Protection |
Material: |
Epoxy Resin |
Product Description
Epoxy resin No.: 305A/BEpoxy resin Specification: 20kg/set [Main Component of epoxy resin glue] A component is resin, B component is curing agent. The main agent305A Curing agent305BColor: Colorless transparent Colorless transparentSpecific gravity: 1.15 0.96Viscosity25°C : 6000-10000CPS [Feature] Epoxy resin 305AB is based on the room temperature, having the features of: (1) translucent(2) low camber(3) natural foam(4) easy to operate, greenhouse curing or heat curing[Scope Of Application] The products of this series are widely used for hairpin ornament, lamp decoration curved crystal glue and so on. Bond and mould filling, and the insulation of other electronic components , moistureproof, potting, confidential encapsulation . [Conditions of usage] 1)Mixing ratio: A: B = 100:50(weight ratio)-->2:12)Hardening conditions: 25°C×10H to 12H or 55°C×2.5H (2 g)3)Usable time: 25°C×60min (100g) [Using Method] 1.Working environment: The container of holding glue please keep clean, A and B part should be in accordance with the weight ratio, weigh accurately , mix fully along the container wall by clockwise and use after 3 to 5 minutes . 2.According to the operational time and dosage of mixing rubber, avoid wasting. When the temperature below 15°C , please put A glue to glue again after warm up to 30°C , easy to operate, (a glue will be thicken when low temperature ); Must be sealed lid after use, avoid product rejection caused by moisture absorption. 3.When the relative humidity is more than 85%, the curing surface easy to absorb moisture in the air, form a layer of white mist, so when the relative humidity is more than 85%, is not suitable for room temperature curing, suggest to use the heat curing. [Warning] 1. The operating environment should be ventilative and should keep away of the fire. Closely sealed after use. 2. Avoid the glue contact the skin and the eye, if contacts the skin, with soap and clear water cleaning, if touches the eye carelessly, uses the clear water to flush and to see a doctor immediately. 3. If the liquid cement has the stratification when used for a long time, use after the agitation evenly, do not affect its product quality 4. Take strict precautions against touching by the kids and entering into the mouth. 5. Please make a trial to avoid usage mistakes before application. [Storage And Packing] Stock the products in the air-tight seal at the temperature of 25°C . The shelf life is half a year. It is available to use based on passing of the test if being beyond the shelf life. Free sample is available.
The properties after hardening |
1)Hardness | shore D | <82 |
2) Withstand voltage | KV/mm | 22 |
3) Flexural strength | Kg/mm2 | 37 |
4) Volume resistivity | Ohm3 | 1x1015 |
5) Surface resistance | Ohmm2 | 5X1015 |
6)Thermal conductivity | W/M.K | 0.57 |
7)Induced electric loss | 1KHZ | 0.42 |
8)Withstand high temperature | °C | 130 |
9) Moisture absorption | % | <0.15 |
10)Compressive strength | Kg/ mm2 | 9.4 |
Shenzhen Jinhua Electronic Materials Co., Ltd engaged in epoxy resin adhesive and the second-processing of hardener agent since 2009, and now we are one of the most professional and competitive epoxy resin glue suppliers in China. Jinhua is professional in development, production and sale of epoxy resin AB glue with the factory area of 2000 square meter. All the equipments in Jinhua are comply to advanced international technology and standard, refer to the excellent formula in domestic and from abroad, and with the high property raw material imported from America, Japan and Germany, every step of the production are with strict test, all of our products have passed RoHS and REACH, make Jinhua to be the leading supplier in this field in China gained high reputation from our customers during the past years.
Jinhua mainly produce epoxy resin AB glue, crystal glue, potting glue, solar panel AB glue, decroation glue, surfboard coating glue, polishable glue and special adhesive, etc. With a very large range of applicaiton including crafts, decoration, fashion jewelry, sticker, promotional gifts, carbon fiber products coating, hard material adhesive, LED channel letters, LED strips potting, name plate, sign boards, solor panel, electronic potting, power encapsulation, molding filling and so on.
With the belief of "honest, harmony, creative, precisencess" and abundant experience, Jinhua people will always offer best solution to worldwide customers. With the principle of Service first, customer formost, we will be your most valuable and faithful cooperater.
We are looking forward to a mutual beneficial cooperation with the friends all over the world.
Welcome to Jinhua!
