| Price: | US $ 2.46-5.39/Square Meter |
|---|---|
| Min Order: | 2000/Square Meter |
| Pay Type: | L/C,T/T,Western Union |
Product Features:
1. Light trasmission: up to 85%
2. Impact resistance: 80 times that of glass, 15 times that of acrylic sheet.
3. Temperature resitance range: -40 to 120°c.
4. Light weight: only 1/12 of the weight of glass at same thickness.
5. Ultraviolet resistance: with UV protective layer.
6. Weather proof
7. Flame resistance: B1 grade
8. Sound and Heat proof
9. Environment friendly
Polycarbonate Characteristics:
| No. | Characteristics | Unit | Data |
| 1 | Impact Strength | J/m | 850 |
| 2 | Light Transmission | % | 85 |
| 3 | Specific Gravity | g/cm3 | 1.2 |
| 4 | Coefficient of Thermal | mm/m °c | 0.065 |
| 5 | Service Temperature | °c | -40 to +120 |
| 6 | Heat Conductivity | W/m2°c | 2.3-3.9 |
| 7 | Tensile Strength | N/mm2 | >60 |
| 8 | Flexural Strength | N/mm2 | 100 |
| 9 | Modulus of Elasticity | MPa | 2400 |
| 10 | Tensile Stress at Break | MPa | >65 |
| 11 | Elongation at Break | % | 100 |
| 12 | Specific Heat | kj/Kgk | 1.17 |
| 13 | Heat Deflection Temperature | °c | 140 |
| 14 | Effect of Soundproof | dB | 3-4 |
PC Twin-wall Hollow Sheets Details:
Thickness: 4-10mm
Size: 1.22m, 2.1m for width, no limit for length
Colors: clear ( transparent ), blue, green, lake blue, opal, bronze for standard, others can be customized.
Unit weight: from 0.75 kg/sqm to 1.70 kg/sqm according to thickness
Lead time: 5 days for one full container at 30% TT deposit received
MOQ: 1x20GP CTN
Packing: both sides with PE Protective films
Applications:
1. Roofing light sheet and sunshade for office building, department store, hotel, stadium,school,amusement center,hospital, ect.
2. Skylight, lighting for corridors, balcony, passages and subway entries, walkways.
3. DIY awning, canopy
4. Conservatories, agricultural greenhouses, zoos, botanical gardens.
5. Industrial Roofing and Glazing
6. Swimming Pools roofing/cover/sheet
Loading:
PC Twin-wall Hollow Sheets Loading Qty:
| Thickness | Sheet Size | Quantity(20GP) | Sheet Size | Quantity(40HQ) |
| (mm) | (mm) | (pcs) | (mm) | (pcs) |
| 4 | 2100*5800 | 550 | 2100*6000 | 1300 |
| 6 | 2100*5800 | 380 | 2100*6000 | 880 |
| 8 | 2100*5800 | 290 | 2100*6000 | 670 |
| 10 | 2100*5800 | 235 | 2100*6000 | 535 |
PC Sheets Storage:
Stored on flat surfaces or wooden bearers with 100mm minimum bearing surface, placed at centre not exceeding 1m.
Make sure the place where you stored is dry, shaded and well ventilated area.
Use an opaque cover (not under flexible PVC coverings), tightly secured, protecting from wind, rain and sun.
Don't store under direct sunlight or without shelter from rain. Indoors torage is always preferable.
PC Sheets Installation:
Step 1: Use screws to attach the base connecting profiles to the roof beams. Make sure the screws not bend, tear or exert excessive pressure on the profile.
Step 2: Place the sheet on top of the base profile support edges, with the side covered by the printed protective film facing upwards.
Step 3: Slide the base under the sheet and attach it to the beam.
Step 4: Place the side spacer profile onto the roof beam and attach the cap to the base by hammering into place with a rubber mallet.
Kindly Remark:
1. As expandable, the drilling diameter must be 1.5 times than that of the bolt.
2. Do not use gaskets made of PVC.
3. PC Sheets can't be installed too tight because there will be thermal expansion and contraction which will adversely affect the installation.
| Prod Model: | APCHS-04 |
|---|---|
| Colors: | Clear, Blue, Opal, Green, Lake Blue, Customized |
| Material: | PC |
| Service Temperature: | -40 to +120 Degree |
| Flame Resistance: | Rated Class B1 |
| Quality Grade: | Grade a |
| Soften Temperature: | 148 Degree |
