Desktop Automatic Liquid Epoxy Glue Dispensing MachineProduct DescriptionPicture show
Parameter: | Model | XYDJ-3313 | XYDJ-4413 | XYDJ-5513 |
| Work area (X/Y/Z)mm | 300*300*100 | 400*400*100 | 500*500*100 |
| Max. speed(mm/see) | 0.1~800/500 | 0.1~800/500 | 0.1~800/500 |
| Dimensions(W*D*H mm) | 485*610*610 | 585*610*610 | 685*700*660 |
| Load Yaxis/Aaxis | 10kg/5kg | 10kg/5kg | 10kg/5kg |
| Resolution | 0.01mm/Axis |
| Repeatability | +/-0.01mm/Axis |
| Program capacity | Min 100group,4000paints/group |
| Operation interface | LCD touch panel/Handhold control box |
| Drive mode | Micro stepping motor/belt |
| Control method | PTP&CP |
| Control method | 3 axis |
| Signals port | 8 Inputs/8 Outputs |
| Net weight | 35kg | 45kg | 55kg |
| Operation environment | Humidity:20-90% RH, Temperature:0-40°C |
| Date storage type | CF Card |
| Power | AC220V 50-60HZ 0.8KW |
Features :1. The glue automatic feeding, safe and silence.
2. Dispense points, lines, surface, circles, arc, irregular curves, three axis controllable.
3. The software has array, horizontal move and rotate operation function.
4. Can set the glue amount, speed and time etc. Stable glue flow and no leaking.
5. Four barrels work at the same time to improve efficiency.
6.glue the size of the thickness, the glue speed, dispensing time, stop the time can be set parameters, the amount of plastic stability,
7.Various functions, such as drawing points, lines, polygons, arcs, circles, irregular curves, continuous tween and three-axis motion;
8. English handhold control box, easy use.
Available Dispensed Material :UV glue, instant glue,silica gel, hot melt adhesive, red glue, silver glue, AB glue, EPOXY resin, COB
black glue, white glue, conductive glue, thermal paste, solder paste, transparent paint, etc.
Application 1. Electrical Products
Electronic parts, integrated circuits, circuit board solder paste, fixed and dust and moisture protection, LCD liquid crystal screen, speakers, headphone, audio, LED, optical lens, SMD transformers, relays.
2. Communication Products
Keypad, mobile phone casing bonding, radio, telephone, Computers, MP4, electronic toys, chassis bonding, switches, connectors, plug cable.
Packaging & ShippingPackage: Wooden cases, suitable for a long distance shipment.
Delivery: In 15-20 working days after order comfirmation
Company InformationSince its establishment in 2004, Xinyuanlijin is committed to the development and manufacture of ultrasonic welding and automation equipment. The product range includes
automatic dispenser, automatic soldering machine, automatic locking screw machine, automatic ultrasonic riveting machine, laser marking machine and other automation equipment to meet the required of many manufacturing customers.
Today, we further enhance the quality of technology and services, to provide customers with more customized products and services. From plan determination to equipment manufacture to on-site service support, we always respond quickly and responsibly to professional technicians, thus saving our customers valuable time.
Nearly every week from customers and abroad come to our factory, we arrange technicians to show the machine operation. Free training is available. Warmly welcome you to visit our factory!
FAQ:Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer small value sample for free charge but do not pay the cost of freight.
Our company supplies different kinds of products. High quality and favorable price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. To perfect our service, we provide the products with good quality at the reasonable price.
