Specifications
1.Advanced pre-setting one week before
2.8 programmable ON/OFF settings
3.To-the-minute setting accuracy
4.LCD displays
DHC12 Weekly Programmable Digital Electronic Timer
·Advanced pre-setting one week before.
·Eight programmable ON/OFF settings.
·To-the-minute setting accuracy.
·Manual override: ON-AUTO-OFF.
·Any one set of time can be changed by using Reset/recall.
·LCD displays real time to Hour/Minute/Second and ON/AUTO/OFF.
·Precise and stable timing control by using crystal oscillator.
Specification
·Voltage: AC170V ~ 240V (50Hz)
·Hysteresis≤1s/d (at 25°C)
·On/off operation: 8 on & 8 off
·Minimum interval: 1 minute
·Weight: Approx 175g
·Display: LCD
·Number of circuits: 1a
·Load capacity: AC250V 16A(resistive)
·Ambient temperature: -10~55 °C
·Power consumption: 4VA
Dimension
Connection
Operating Instruction
1. First time use this timer swich, please input AC and let battery recharge, after then press reset key.
2. At first time, the timer swich is in 24h mode. If you want to change to 12h mode please press on
'CLOCK ' key 5 sce. And LCD will display AM If you want rechang to 24h mode, please press on 'CLOCK' key 5 sce to return.
3. Programming:
| Step | Key | Programming |
| 1 | Press PROG | Setting 1 ON time (display 1 on ) |
| 2 | Press HOUR/ MIN | Set hours and minutes |
| 3 | Press PROG | Setting 1 off time (display 1 off ) |
| 4 | Press DAY | Select days of week ( If you want same set in every day,you need not press this key) |
| 5 | Press HOUR/ MIN | Set hours and minutes |
| 6 | Repeat step 2-6 | Set 2-8 on/off time |
| 7* | Press CLOCK | End |
**If you need not 8 time setting press 'CLOCK' key to the end.
4. Clock Setting
a.Press 'CLOCK' and 'HOUR' together till correct hour is shown.
b.Press 'CLOCK' and 'MIN' together till correct min is shown.
c.Press 'ON/AUTO/OFF' key to display ON AT or AT OFF. (If this clock in your program is ON selects ON AT, and this clock in your program is OFF selects AT OFF)
5. Press 'ON/AUTO/OFF' key can select timer swich to ON/OFF/AUTO.
6. For cancel engagements, press 'RST / RCL' then '- -:- -' is displayed on LCD to confirm cancel. May press 'RST / RCL' again to resume initial setting.
