Sponge Door Seal
Parameters:
Width: 3000/3200/3400 mm
Height: 3000/3200/3400 mm
Dock shelter depth: 600 mm
Sponge thickness: 25/20 mm
PVC Color: Black/Blue
Thickness of front PVC sheet: 0.9 mm
Thickness of side PVC sheet: 0.5 mm
Height of top PVC curtain: 1000 mm
Width of side PVC curtain: 400 mm
Frame: High quality steel strips, covered by transparent PVC or Color PVC material .
Operating temperature range, ºC: -35…+70
Features:
1.Installation applied for requirements of high insulation and strong sealing;
2.High efficient air blower offering stable air pressure;
3.After loading & unloading, the air bag exhausted and packed into small package, guarantee a longer
service life of dock seal.
Details
| Width, mm 3400 3600 |
| Height, mm 3400 3800 |
| Moving range of top air bag 1200 |
| Moving range of Side air bag 800 |
| Top Mask 500 |
| Side Mask 250 |
| Profile color Aluminum (RAL9006) |
| Panel color White (RAL9003) |
| Control mode Switch/Platform Control Unit |
Specification:
| Control system |
| Power supply 380,50Hz |
| Power 0.75kw |
| Control unit Outside |
| Protection class IP54 |
| Airbag average time 25s |
| Working temperature -35ºC to +70ºC |
| PVC Curtain 3.6kg/m |
| Thickness 3mm |
| Unit Weight 3.6kg/m |
| Airbag 0.5mm |
| Material Cordura 1000 |
| Thickness 0.5mm |
| Unit Weight 0.4kg/m |
| The largest tensile ability >290N/mm² |
| Insulation panel |
| Thickness 50mm |
| Color White (RAL9003) |
