There are many materials can be engraved, such as wood block, bamboo product, acrylic sheet, glass, PVC sheet, double-color sheet, ceramic tile, rubber, plastic, marble, bowlder, crystal, leather and cloth. etc. Nonferrous materials.
Good Features:
1. 64 DSP high speed processor: Adopts 64 DSP high speed control system, which highly improved the data processing speed and stability.
2. Support of USB and U disc: USB connect to the machine or U disc independently, which can use only one computer to control many laser machines.
3. Storage function: Large storage Function, which can store hundreds of files for offline operation.
4. Real time regulation:Users can regulate the laser power according to needs to improve the engraving effect.
5. Easy operation: Control panel and software system have both English and Chinese language so that satisfies the needs of different customers.
6. Rotary clamps for engraving cylinders(optional): can engrave not only sheets, but also roll materials and cylinders such as pencil vase, flute, bottle and so on.
Engraving size: 600*400mm 900*600mm 1200*800mm 1400*900mm 1600*1200mm 1500*2500mm
Machine feature
1. This trademark laser cutting machine is largely used for cutting all kinds of labels, trade mark, embroidery samples
2. The machine is adoption of leading technology in this industry, seek cutting edge according to different colors of brim or positioning characteristic point of trademark. Realize automatically positioning cutting and punching. Copletely solve inevitable error caused by the manual position during the traditional laser cutting process.
3. It signs that laser technology and automatic technology as well as man-made visual intellectual technology combined harmony, according to using of pickup positioning system. There is no question that it can do a good help for getting, continuous and positive productivity and improving productivitiy as well.
4. Time is profit the software design with the shortest cutting path key point of automatic positioning cutter. It can save working time about 10-20% in average that is to say increasing the profit about 10-20%, comparing with software without the shortest cutting path design.
5. The achievement of high-speed and continuous curve cutting function is based on powerful data treatment capacity of top DSP technology, special design of software in computer and the perfect makeup of precise machinery system. It will neither change for cutting line nor distorting for curve cutting, in the case of high-speed running.
Technical parameter
Laser type: Hermetic and detached CO2 laser tube
Laser-wavelength: 10600nm
Laser power: 60-180W
Working area: According to machine working size
Engraving speed: 0-64000mm/min
Cutting speed: 0-36000mm/min
Resetting positioning accuracy 0.01mm
Resolution ratio: 0.025mm
Highest scanning precision: 2500DPI
Graphic format: AL, CDR, BMP, JPG, DST, PLT, DXF, DWG, TIFF, PSD
Supported software: CorelDraw, Photoshop, AutoCAD etc.
The smallest cutting characters: chinese 2.0×2.0, english 1.0×1.0 Character2.0mm×2.0mm, English 1.0mm×1.0mm
Power supply: 220V/50HZ
Whole power: <1000W
Operating temperature: 0ºC-45ºC
Operating humidity: 5-95%(Free of condensed water)
Shanghai Yuetai Machinery Co., Ltd., is an experienced manufacturer&exporter in Signage equipment. We have rich experiences in R&D, manufacturing and marketing in this field. China's first a inkjet printing and laser equipment integrated manufacturers. More than 80% products are exported to more than 60% countries and regions around the world. For some machines, such as wide format digital inkjet printer, CNC router / engraving system, laser engraving machine, cutting plotter, cold laminator, hot stamping machine etc., we have more than seven years professional experiences.
In the past years, our products have won high reputation for their high quality in domestic market as well the overseas market. They have many excellent features: Easy to be handled, sensitive control system, stable&reliable quality, low electricity consumption, low noise, long life time, etc.
The mission of Goldensign is to specialize in digital sign equipment and realize two wins between Goldensign and clients, and provide the over-value products and service for our distributors.
We are working hard to pursue the higher and upper goals.
