Main Highlights:
It is a latest version from SuperImage LUVA4 UV Flatbed Printers.
More quick, More High efficiency, and More Stable.
This Flat-bed Printers can print directly textile, cloth, T-shirt, Metal board, Plastic board, Ceramic, Porcelain, Slate, Stone, Acrylic board, ABS board, Wood, Glass, Crystal, Leather, Mobile Covers, Signages, etc all types of materials, by using sublimation inks, light eco solvent inks, textile inks, reactive inks, etc all types of inks.
>>> Epson 6 Colors print head is adopted. The print head afford C, M, Y, K, LC, LM 6 colors. And each print head has 9*6=540 nozzles(6 lines, 90 nozzles each line),
Totally its max. Print resolution can reach to 5760*1440 dpi.
>>> The advanced and unique Flat-bed transfer system is adopted. The whole printing process can be stable and high efficiency. More the max. Print height can reach to 50mm, which make many board style print Materials can be printed.
Also A4 print size can satisfy some normal signs and photos processing.
>>> Wide Ink applicability: Led uv curable ink for Epson.
Mainly used to print some media directly, like abs,plastic, glass, ceramic, metal, wood, porcelain, Floor, plastic board, Acrylic, KT board, Slate, Metal, Stone, Leather, etc.
Main Data:
Brand: SuperImage
Printer Name: A4 UV Flatbed Printer/A4 LED UV Flat-bed Printers
For plastic, metal,glass,ceramic,abs,acrylic, KT board, Slate, stone,leather, etc rigid and flexible materials,
Printer Model: SuperImage LUVA4
Print Tehnology: Piezo Print On Demand
Print Head Model: Epson
Print Head Quantity: 1
Print Colors: CMYK LC LM
Max. Print Resolution: 5760*1440dpi
Min. Droplet Size: 1.5pl
Ink Supply: 6 Colors Continual Ink Supply System
Ink Cartridges Capacity: 6 Colors 100ml
Max. Print Size: A4 valid print area(300mm*165mm)
Max. Print Height: 50mm
Ink Types: LED UV Curable inks
Print Method: Auto Double-surface printing.
Interface Types: USB2.0
Machines Size: 650mm*470mm*430mm(L*W*H)
The pallet' spread size: 950mm*470mm*430mm(L*W*)
Machine Net Weight: 38KG
Package Size: 74CM*56CM*51CM(L*W*H), 0.22CBM
Wooden Case Size: 80cm*60cm*60cm(L*W*H).
Machine Gross Weight: 45KG
Wooden Case Package Weight: 75KG.
Standard Accessories: RIP, Driver CD, Guide Manual CD, CISS Kits(equipped)
Main Advantages:
1). Wide applying arrange and fields.
2). Fine workcrafts, and Excellent quality
3). Good stability and compatibility
4). Converted from Brand New Epson Printers
5). Easy installation and operation.
6). Full technical support for installation and replacing afforded if neccessary.
7). Consistent quality & reputation.
8). Low Inverstments and printing cost.
9). Low investment and high efficiency, and multi-function.
10). A4 size led uv, used in many fields.
