Product Specifications
| Prod Model: |
BLS |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Materials: |
Stainless Steel304,316 |
| Diameter Of Internal Tank: |
400-3000mm |
| Diameter Of Jacket: |
500-3200mm |
| Heat Preservation Layer: |
600-2400mm |
| Motor Power: |
0.6-37kw |
| Rotation Speed Of Blending: |
50-120r/Min |
Product Description
JJ crystal can/crystallizing tank
Structure characteristics:
The crystallizing tank is made of imported 316L or 304 stainless steel.
The internal wall adopts electrolytic mirror polishing or mechanical polishing.
The external wall adopts 304 completely welding structure for heat preservation.
The exterior surface adopts mirror polishing or semi-luster polishing.
The crystallizing tank can endure 121ºC high temperature sterilization.
The shaft seal adopts special sanitary mechanical seal to guarantee the material is out of pollution.
The crystallizing tank can adopt frequency conversion speed control device and the rotation speed of mixing shaft has wide regulation range.
Configuration of machine:
1. 0.2 µm ventilation hydrophobic filter
2. Sanitary pressure meter
3. Sanitary rapid open connector
4. Temperature monitoring device
5. 2 view mirrors
6.Cleaning ball
7. Nitrogen inlet
| Specification | Diameter of
internal tank (Φ mm) | Diameter of jacket
(Φ mm) | Heat preservation
layer (Φ mm) | Motor
power (kw) | Rotation
speed of blending |
| 30 | 400 | 500 | 600 | 0.6-1.1 | 60-120 |
| 50 | 500 | 600 | 700 | 0.6-1.1 | 60-120 |
| 100 | 550 | 650 | 700 | 1.1-1.5 | 60-120 |
| 150 | 600 | 700 | 900 | 2.2 | 60-120 |
| 200 | 650 | 750 | 1000 | 2.2 | 60-120 |
| 300 | 800 | 900 | 1100 | 2.2 | 60-120 |
| 500 | 900 | 1000 | 1200 | 2.2 | 60-120 |
| 800 | 1100 | 1200 | 1300 | 4 | 60-120 |
| 1000 | 1200 | 1300 | 1400 | 4 | 60-120 |
| 1500 | 1300 | 1400 | 1500 | 4 | 60-120 |
| 2000 | 1400 | 1500 | 1600 | 4 | 60-120 |
| 2500 | 1400 | 1500 | 1700 | 7.5 | 90-120 |
| 3000 | 1400 | 1500 | 1800 | 7.5 | 90-120 |
| 3500 | 1400 | 1500 | 1900 | 7.5 | 90-120 |
| 4000 | 1500 | 1600 | 2000 | 7.5 | 60-120 |
| 5000 | 1600 | 1700 | 2100 | 7.5 | 60-120 |
| 6000 | 1800 | 1900 | 2200 | 15 | 100-120 |
| 8000 | 2000 | 2100 | 2300 | 15 | 100-120 |
| 3200 | 3000 | 3200 | 2400 | 37 | 50-120 |
