Stone Engraving Machine for Marble Granite with Two Heads Od-1218-2

Name: Stone Engraving Machine for Marble Granite with Two Heads Od-1218-2
Brand: china-crystals.com
SKU: 783997995
Availability: InStock
Rating: 4.8 (39 reviews)

Price:	US $ 2000-5000/Piece
Trade Terms:	FOB,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,Paypal

Contact Supplier

Showroom Product Company Profile

stone engraving machine for marble granite with two heads OD-1218-2

Application Materials :
Artificial stone, Marble, Granite, Ceramic Tile, Tombstone, milestone, Terrazzo, Limestone, Sandstone, Travertine, Quartzite, Slate, grindstone ,Jade, crystal, plexiglass, aluminum composite panel, aluminum block, copper, wood, MDF, hardwood, plywood and so on.
Application Industries :

Applications:
Advertisement engraving, advertisement cutting, stone processing cutting, Cu and Al molding cutting, mold manufacturing cutting, wood processing cutting, wood door manufacturing cutting, craft manufacturing cutting, light box cutting, building mold cutting, indoor decoration cutting, wave board processing cutting, light equipment, mold processing cutting, sign and mark manufacturing cutting, acryl board processing cutting, stamp cutting.

N	parameters description		parameters
		X	1200 mm
1	Working zone	Y	1800 mm
		Z	300 mm
		X	Rack gear and pinion drive
2	Transmission systems	Y	Rack gear and pinion drive
		Z	Ball screw drive
		X	square linear rails
3	Guide rails system	Y	square linear rails
		Z	square linear rails
		X	Stepper motor
4	Drive systems	Y	stepper motor
		Z	stepper motor
		Power	4.5KW
		Speed	24000rpm
5	Spindle	Cooling type	water -cooling
		Origin	China
		Collets	ER20
6	Spindle inverter		RITUO
7	Distance from spindle nose to table		>= 200 mm
8	Table size		1680*3000mm
9	Max travel speed		>30m/min
10	Max engraving speed		>10 m/min
11	Resolution		<=0,005 mm
12	Cutting Accuracy		<= 0,05 mm
13	Repeatability		<=0,03 mm
14	Control systems/Operation system		NC studio
15	software		TYPE3/Artcam /Ucancam /JDpaint
15	Power:		AC380V±10% / 50~60Hz
16	Machine weight kg		800KG

Prod Model:	OD-1218-2
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Working Size:	12001800300mm
Spindle:	4.5~7.5kw Water Cooled Spindle
Motor:	Servo Motor or Stepper Motor
Control System:	Ncstudio /DSP Hand Controller
Software Ware:	Artcam /Type3
Warranty Time:	1 Year
Delivery Time:	15 Days
Spindle Layout:	Spindle Over
Spindle Number:	Single-Spindle
Feed Mode:	Manual
Controlling Mode:	CNC
Certification:	SGS

NANJING AUTO E&T Co., Ltd is a specialized CNC router manufacturing company which focuses not only on machine production but also on R&D activities as well. Our company is devoted in the research and development of carving CAD/CAM technology and CNC technology. Our CNC routers have obtained remarkable achievements in the precise carving machine design as well as artistic carving technology, and also have realized industrialization of computerized numerical control technology.

Our company produce CNC routers which are sold in various markets of Europe and America. We have received a good reputation and established a leading position in carving machine lines in those countries. With several years of rapid development, our products are applied for advertisement decoration, marking, label industry, woodworking, mold manufacturing as well as crafts and gifts. We are still trying our best to innovate our products to assist our worldwide customers in lowering their costs and increasing their return.
