Price: | US $ 30000-300000/Set |
---|---|
Trade Terms: | FOB,CFR,CIF |
Min Order: | 1/Set |
Pay Type: | L/C,T/T,Paypal,Western Union |
The coating experts of your own company:Full set solution for the coating production.
HCVAC can help you to enter the PVD coating easily by our vacuum coating machine and full range service. We will provide with most suitable technology according to your requirements.
We will make the special coating solution for each customer; combine the full set production technics to meet your requirements, to ensure high efficiency of production.
We developed a complete after-sales system and effective service measures. Company now owns a professional after-sales service team with more than ten experienced engineers.
ISO 9001 standard to ensure the quality can meet the customer's requirements.
For more information, please feel free to contact us or visit our website: www.hcvacuum.com!
Mode Dimension | JTL-900 | JTL-1100 | JTL-1250 |
900*1000mm | 1100*1000mm | 1250*1100mm | |
Coating mode and main confirguration | Six multi-arc targets + one set of column targets + one set of plane rectangle magnetron sputtering targets | Six multi-arc targets + a pair of twin (MF)magnetron sputtering targets | Twelve multi-arc targets + two sets of plane rectangle magnetron sputtering targets+ a pair of twin (MF)magnetron sputtering targets |
Power source | Electric arc power, DC magnetron power, MF magnetron power, filament power, pulse power, linear ionized source. | ||
Process gas control | Quality flowmeter + electromagnetism ceramic valve | ||
Vacuum chamber structure | Vertical single(side) door, pump system postposition, double water-cooling | ||
Vacuum system | Molecule pump +Roots pump +Mechanical pump(5.0*10 -5 Pa) Diffusion pump +Roots pump +Mechanical pump(5.0*10 -4 Pa) | ||
Workpiece baking temperature | Normal temperature to 350 centi-degree PID control, radiation heating. | ||
Workpiece motion mode | Public rotation Frequency control: 0-20 rotation per minute | ||
Measure mode | Number display composite vacuum gauge: from atmosphere to 1.0*10 -5 Pa | ||
Control mode | Manual/Automatic/PC/PLC + HMI/PC four choice of control mode | ||
Remark | We can design the dimension of the equipment according to customer's special technique requirement. |
Prod Model: | JTL-0910, JTL-1110, JTL-1212 |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product: | Titanium Nitride Gold PVD Vacuum Coating Machine ( |
Business Type: | China Manufacturer/Supplier |
Size: | Customized |
Structure: | Vertical, Single Door |
Control System: | Manual Automatic Semi-Automatic All-in-One |
Operating System: | PLC Touching Screen |
Coating Color: | Gold, Rosegold, Silver, Black, Blue, Ect |
Service: | Installment, Training, After Sale Service |
After Sales-Service: | Engineers Available to Service Machinery Overseas |
Brand: | Hcvac/Huicheng China |
Type: | Coating Production Line |
Coating: | Vacuum Coating |
Substrate: | Glass, Metal, Ceramic, Alloy, Crystal, Mosaic |
